Location：Home > Photovoltaic Test Products > Subassemblies > Grounding continuity Tester Model: CHT-2813W

Yanzhi Grounding continuity Tester Model: CHT-2813W

Apply

Satisfied: IEC61730-MST 13; UL1703-25

For electrical products, one of the most basic requirements is that the shell can not have the risk of electric shock, generally the shell is required to be grounded. Due to the limited connection site, in order to ensure that the whole shell is grounded, the interior of the shell needs to be electrically conductive, and the resistance should be small enough, so that a little grounding is equivalent to the grounding of the whole shell. This test equipment is to verify the circuit continuity between the contact sites.

Online Contact
  • Product Features
  • Technical Parameters

1) 4 line structure, 2 line current, 2 line test distal voltage;

2) Current size, the test time can be set in advance;

3) Resistance value can be automatically calculated, set with a high resistance value alarm function.

Model

CHT-2813W

Current range

10-60A

Current resolution

0.01A

Current accuracy

±2% +3digit

Voltage range

0-6V

Voltage ripple

300mV

Resistance range

0.00uΩ  ～ 600.00mΩ

Resistance resolution

0.01mΩ@(600.00mΩ  ～ 100.00mΩ);

0.001mΩ@(99.999mΩ  ～ 10.000mΩ);

0.1uΩ@(9.9999mΩ  ～ 1.0000mΩ);

0.01uΩ@(999.99uΩ  ～ 0.00uΩ);

Resistor accuracy

±2% +3digit

Duration

0.5s  ～ 999.9s(0.0s means continue testing

Size-time resolution

0.1s

Duration accuracy

±(0.1%setting+0.05s)
