Principle of instrument

The light emitted by the light source is divided into two beams by the beam splitter (similar to the semi-transparent semi-reverse mirror), one beam reaching the moving lens and the other beam reaching the fixing lens. Two beams of light are reflected by the fixed mirror and the moving mirror and then return to the beam splitter, and the moving mirror moves in a straight line at a constant speed, so the two beams of light after the beam splitter form the light path difference and produce interference. After the beam splitter meets, the beam splitter passes through the sample pool, and reaches the detector through the sample, and then the signal is processed by Fourier transform to finally obtain the infrared absorption spectrum of transmittance or absorbance with wavelength or wavelength.

Product features

1) Innovative and unique design advantages:

2) high stability optical system: precision optical high hardness platform;

3) the performance of the electronic system: DSP controlled electromagnetic drive interferometer, motion mirror permanent collimated; intelligent;

4) protection system: industrial grade resistance moisture-proof + physical moisture-proof;

5) Diversified accessories selection: any selection of test accessories;

6) Convenient software operating system:

Whether you have contact with Fourier infrared software, can quickly and skillfully operation; optional laser frequency calibration mode, both national standards or measurement specifications can meet; unique data acquisition preview full monitoring mode, collection process view;

7) has a variety of professional infrared atlas libraries:

In addition to the routine retrieval, users can customize new spectrum libraries and add maintenance. Atlas library includes: national pharmacopoeia spectrum library, national animal pharmacopoeia spectrum library, rubber spectrum library, gas spectrum library, polymer spectrum library, protein and amino acid spectrum library, judicial spectrum library (dangerous goods, chemicals, drugs, etc.), inorganic spectrum library, organic spectrum library, solvent spectrum library, spectrum library of food additives, flavor spectrum library, paint spectrum library and so on reliable optical system;

8) Reliable sealed-type interferometer design:

Using a beam splitter with a moisture-proof film and a large capacity of the reusable desiccant box, reaching 5 times the moisture-proof ability of similar products. Visual color-changing window, easy to observe and replace the molecular sieve. Some optical parts adopt high precision diamond lathe processing, the system has high consistency and stability;

9) Positioning and installation mode of the needle without adjustment; high stability;

10) The interferometer adopts imported Angle cone mirror, with extremely high reflectivity and Angle accuracy; using high performance long-life ceramic light source, luminous efficiency up to 80%; high sensitivity imported DLATGS receiver; humanized design;

11) Large sample warehouse design to facilitate the expansion of various infrared accessories;

12) Open the sample warehouse door design to greatly reduce the external air interference from the experiment; the instrument design is compact, compact and light; modular design, simple maintenance.
